Vaste koppeling
Storz 25-D KA 31 mm, binnendraad 1", 16 bar AluminiumArt.-Nr.: 1732905Leveranciersnummer: 2404.3110EAN: 4047322254571
Aantal:
1 stukPakketgeschikt
Prijs en voorraad zichtbaar na login
Beschrijving
Storz adapter, Aluminium, Storz size 25-D, Tappet distance 31 mm, G 1 IT, Operating pressure max. 16 bar, Temp. -40 °C to 110 °C. High-quality series in forged aluminium. For quick and simple hose connections. User friendly, the coupling elements are joined without damaging the seal. Applications: Water lines, industrial plant engineering, firefighting.
Specificaties
Bracket spacing
31 mm
Internal thread
G 1 IG
Material
Aluminium
Max. operating pressure
16 bar
Operating temperature max.
110 °C
Operating temperature min.
-40 °C
Sealing material
NBR
Storz size
25-D
