Hydraulische moer
HMV 54E SKF MaProArt.-Nr.: 1385053Leveranciersnummer: HMV 54Edouanetariefnummer: 84122180EAN: 7316577080158
Aantal:
1 stukPakketgeschikt
Prijs en voorraad zichtbaar na login
Beschrijving
Facilitates easy and quick application of the high drive-up forces required for mounting bearings on tapered seatings. The hydraulic nut can also be used for dismounting bearings mounted on either adapter or withdrawal sleeves.
Specificaties
Breedte
48 mm
Buitendiameter
368 mm
Connection thread
Tr 270x4
Kolbenaußendurchmesser
352 mm
Kolbenbreite
9 mm
Kolbenfläche
19800 mm²
Kolbeninnendurchmesser
272 mm
Maximaldruck
80 Mpa
Maximale Kolbenschiefstellung
12 mm
Maximum pressure
800 bar
Screw thread
ISO 2901-1977 tolerance class 7H
Weight
20,50 kg
