Beschrijving
Inspection Camera GIC 12V-4-23 C, The GIC 12V-4-23 C Professional inspection camera is the ideal tool for HVAC/plumbers, car mechanics, or electricians. It has a large 4.3” monitor that displays clear, high-definition images of 800 x 480 pixels, enabling quick and intuitive analysis of pipes, ducts, or other hard-to-reach areas. Image orientation is easily determined thanks to the handy Up Indication feature that always points upwards. This ergonomic camera is robustly designed for use on tough jobsites and hard-to-reach spaces. It comes with an IP67 rating for the camera head, protecting it from dust and short periods of immersion in water, and IP54 dust and splash water protection for the tool. This inspection camera is ideal for multiple tradespeople applications such as inspecting the interior of distribution boxes, pipes, and wall cavities as well as for hydraulic systems and applications in the automotive sector. Photos taken with the GIC 12V-4-23 C Professional are easily transferred via USB-C® cable. Camera cable for GIC, 8.3 mm diameter, 1.5 m length (1 600 A02 R6M), Hook, magnet, mirror, USB-C™ Cable, AA1 alkaline battery adapter (1 608 M00 C1B), 4 x 1.5 V LR6 battery (AA)
Specificaties
Beeldresolutie
1280 x 720
Data transmission
USB-C®
Diameter camerakop
8.3 mm
Documentatie via
Foto
Focusafstand
30 - 80 mm
Fokusentfernung bis
80 mm
Fokusentfernung von
30 mm
Gewicht
0.70 kg
Gezichtsveld (FOV)
75 °
Lengte van de camerakabel
150 cm
Max. 30 min onderdompeltijd voor camerakabel in
Zout water (zoutgehalte 26,5%)
Resolutie display
800 x 480 px
Schermgrootte
4.3 "
Stof- en spuitwaterbescherming, camerakabel
IP 67
Stof- en spuitwaterbescherming, gereedschap
IP 54
