Beschrijving
MicroteQ teeth (manufactured in-house) from high-density carbide combined with robust tooth shape ideal for universal use Depending on the number of teeth, different results can be achieved with all Expert for Wood Circular Saw Blades, which feature an ATB (Alternate Top Bevel) tooth geometry: when equipped with a high tooth count, the blade delivers clean cuts, whereas a low number of teeth guarantees solid and efficient cuts.
Specificaties
Aantal tanden
48
Bohrung mm
30 mm
Boring
30 mm
Buitendiameter
165 mm
Buitendiameter mm
165 mm
Core sheet thickness (b2) mm
1,6 mm
Cutting width (b1) mm
2,6 mm
Freiwinkel ° β
15
Max. Rotationsgeschwindigkeit (U/min)
11500 U/min
Max. rotatiesnelheid
11500 U/min
NL/Durchmesser TKS
2/7/42
Snijbreedte (b1)
2.6 mm
Snijbreedte (b1) mm / bladdikte (b2) mm
2.6/1.6
Snijhoek
5 °
Snijresultaat
4
Spanwinkel ° α
5
Stambladsterkte (b2)
1.6 mm
Tandvorm
WZ
Vrijloophoek
15
