Beschrijving
The Expert for Fibre Cement Circular Saw Blade is highly durable when cutting fibre cement. It features PCD (polycrystalline diamond) teeth, providing a long lifetime of usage. Its performance is further supported by ProteQtion coating, which prevents corrosion and delivers reliable cutting while reducing friction. Additionally, the blade is specially designed with anti-vibration slots for particularly smooth cutting, considerably less noise and significantly reduced vibration. The Expert for Fibre Cement Circular Saw Blade features TCG (Triple Chip Grind) teeth for high robustness and a long lifetime.
Specificaties
Aantal tanden
4
Bohrung mm
30 mm
Boring
30 mm
Buitendiameter
170 mm
Buitendiameter mm
170 mm
Core sheet thickness (b2) mm
1,6 mm
Cutting width (b1) mm
2,2 mm
Freiwinkel ° β
10
Max. Rotationsgeschwindigkeit (U/min)
11200 U/min
Max. rotatiesnelheid
11200 U/min
NL/Durchmesser TKS
2/7/42
Snijbreedte (b1)
2.2 mm
Snijbreedte (b1) mm / bladdikte (b2) mm
2.2/1.6
Snijhoek
10 °
Snijresultaat
2
Spanwinkel ° α
10
Stambladsterkte (b2)
1.6 mm
Tandvorm
TCG
Vrijloophoek
10
