Beschrijving
The Optiline Wood Circular Saw Blade delivers precise quality cuts in all types of wood. Its high-quality precision-ground carbide teeth enable clean cuts, while its base blade made of dimensionally stable SK5 hardened steel (> 40 HRC) ensures accuracy. Furthermore, the blade's expansion slots lower vibration during use, which dampens noise and reduces heat development. Use this saw blade in all types of wood and wooden materials. Depending on the number of teeth, different results can be achieved with all Optiline Wood Circular Saw Blades, which feature ATB (Alternate Top Bevel) tooth geometry: when equipped with a high tooth count, the blade delivers clean cuts, whereas a low number of teeth guarantees solid and efficient cuts.
Specificaties
Aantal tanden
60
Bohrung mm
30 mm
Boring
30 mm
Buiten-Ø
190 mm
Buitendiameter
7 1/2 Inch
Buitendiameter mm
190 mm
Core sheet thickness (b2)
1.6 mm
Core sheet thickness (b2) mm
1,6 mm
Cutting angle
15 °
Cutting result
4
Cutting width (b1)
2.6 mm
Cutting width (b1) mm
2,6 mm
Cutting width (b1) mm / blade thickness (b2) mm
2,6/1,6 mm
Freiwinkel ° β
15
Materiaal
HM
Max. Rotationsgeschwindigkeit (U/min)
8000 U/min
Max. rotation speed
8000 U/min
NL/Durchmesser TKS
7/42
Outer diameter inch
7 1/2 "
Snijbreedte
2,6 mm
Spanwinkel ° α
15
Tandvorm
WZ
