PTFE-composietmof
PCM 040506 E/VB055 loodvrij, SKFPTFE-Verbundwerkstoff
Art.-Nr.: 1305764Leveranciersnummer: PCM 040506 E/VB055douanetariefnummer: 84833080EAN: 7316572196328
VPE (Verpakking): 50 stukAantal:
50 stukPakketgeschikt
Prijs en voorraad zichtbaar na login
Beschrijving
SKF PTFE composite straight (cylindrical) bushings are suitable for oscillating, rotating and linear movements, and can accommodate radial loads. Despite their thin-walled design, they can accommodate heavy loads. They also provide good heat dissipation, therefore enabling relatively high sliding velocities.
Specificaties
Boringdiameter
4 mm
Breedte
6 mm
Buitendiameter
5,5 mm
Dynamische Tragzahl
1.9 kN
Materiaal
PTFE-Verbundwerkstoff
Statische Tragzahl
6 kN
