Beschrijving
Mitre Saw GCM 10 GDJ, The GCM 10 GDJ Professional mitre saw represents the union of state-of-the-art performance and revolutionary design. Bosch’s Axial-Glide™ system makes for consistent precision and smooth gliding action, even in limited working spaces. Safe and comfortable: upfront bevel controls ensure quick and easy adjustment, without the risk of having to reach behind the saw. The saw head can be locked in the cut position, achieving the maximum cutting capacity for chopcuts. Ideally used on hard wood, soft wood, wood composites, MDFs, as well as dimensional and engineered lumber, this saw is the perfect choice for all trimming tasks in jobs like carpentry, remodelling, window installation, and cabinet building. The saw is compatible with the following Bosch stands: GTA 2500 Compact, GTA 2500 W, GTA 2600, and GTA 380 The GCM 10 GDJ Professional also features a large easy-to-read bevel and mitre scale as well as tall fences and machined squares for optimal material support. 1 x circular saw blade, Expert for Wood, 254 x 30 x 2.4 mm, 60 (2 608 642 530), Clamp (1 609 B06 203), Dust bag (spare part number 1 609 B00 506)
Specificaties
Afstellen verstek rechts
47 °
Diameter zaagbladboring
30 mm
Gereedschapafmetingen (breedte x lengte x hoogte)
813 x673 x521 mm
Gewicht
31.6 kg
Leerlaufdrehzahl, bis zu
5.000 min-1
Neigingsinstelling
52 ° / 60 °
Neigingsinstelling links
52 °
Neigingsinstelling rechts
60 °
Nominaal ingangsvermogen
2000 W
Onbelast toerental
5000 min-1
Snijcapaciteit 0°
80 x 306 mm
Snijcapaciteit 45° helling
54 x 296 mm
Snijcapaciteit 45° verstek
80 x 216 mm
Snijcapaciteit bij 0°, breedte
306 mm
Snijcapaciteit bij 0°, hoogte
80 mm
Snijcapaciteit bij 45° verstek, breedte
296 mm
Snijcapaciteit bij 45° verstek, breedte
216 mm
Snijcapaciteit bij 45° verstek, hoogte
54 mm
Snijcapaciteit bij 45° verstek, hoogte
80 mm
Verstekverstelling
47 ° / 47 °
Verstekverstelling links
47 °
Zaagbladdiameter
254 mm
