Vermindering
Storz 52-C, KA 66 mm Aluminium 2406.6640Art.-Nr.: 1732916Leveranciersnummer: 2406.6640EAN: 4047322254861
Aantal:
1 stukPakketgeschikt
Prijs en voorraad zichtbaar na login
Beschrijving
Storz reducer, Aluminium, Storz size 52-C, Tappet distance 66 mm, Flange DN 40, Operating pressure max. 16 bar. High-quality series in forged aluminium. For quick and simple hose connections. User friendly, the coupling elements are joined without damaging the seal. Applications: Water lines, industrial plant engineering, firefighting.
Specificaties
Anzahl Schraubenlöcher
4
Betriebsdruck max.
16 bar
Betriebstemperatur max.
110 °C
Betriebstemperatur min.
-40 °C
Dichtmaterial
NBR
Flens
DN 40
Knaggenabstand 1
66 mm
Lochkreisdurchmesser
110 mm
Material
Aluminium
Storz-Größe
52-C
