Vermindering
Storz 52-C, KA 66 mm Aluminium 2406.6650Art.-Nr.: 1732917Leveranciersnummer: 2406.6650EAN: 4047322254878
Aantal:
1 stukPakketgeschikt
Prijs en voorraad zichtbaar na login
Beschrijving
Storz reducer, Aluminium, Storz size 52-C, Tappet distance 66 mm, Flange DN 50, Operating pressure max. 16 bar. High-quality series in forged aluminium. For quick and simple hose connections. User friendly, the coupling elements are joined without damaging the seal. Applications: Water lines, industrial plant engineering, firefighting.
Specificaties
Bracket spacing 1
66 mm
Flens
DN 50
Lochkreisdurchmesser
125 mm
Material
Aluminium
Max. operating pressure
16 bar
Number of screw perforations
4
Operating temperature max.
110 °C
Operating temperature min.
-40 °C
Sealing material
NBR
Storz size
52-C
