Ganter

Zeskantbout, EPDM, hygiënisch ontwerp

GN 1580-M4-10-MT-E roestvast staal
NI - Roestvrij staal
Art.-Nr.: 1487383Leveranciersnummer: 1580-M4-10-MT-EEAN: 4045525794368

Aantal: ​​ 1 stukPakketgeschikt
Artikel in 204 varianten beschikbaar:
Op korte termijn verkrijgbaar

Beschrijving
Screws GN 1580 are certified according to EHEDG guidelines and are therefore ideal for use in hygienic areas. The sealed mounting surface enables components to be mounted without dead spaces. The high quality finish as well as the large corner radii and closed surfaces prevent adherence of dirt and facilitate cleaning.
Specificaties
Gewicht
0.004 kg
L2
14
Lengte l1 (zonder schacht)
10
Materiaal
NI - Roestvrij staal
Materiaal (afsluitring)
E - EPDM
Oppervlakte
MT - mat (Ra < 0,8 µm)
RoHS
Ja
SW
7
Schroefdraad d1
M 4
d2
11
d3
11.8
k
9.5
