Elesa

Positie-indicator oranje

GN 953-0002.5-FN-R-OR Elesa CE.83199
KT - Kunststof
Art.-Nr.: 1216435Leveranciersnummer: 953-0002.5-FN-R-OREAN: 4045525660434

Aantal: ​​ 1 stukPakketgeschikt
Artikel in 964 varianten beschikbaar:
Op korte termijn verkrijgbaar

Beschrijving
Position indicators GN 953 have a direct coupled drive with digital indication. The two housing parts are ultra-sonically welded, thus the housing is particularly sturdy and compact. The foam rubber seal prevents the transmission of vibration to the counter and also acts as a seal. The numbers are easily legible and they are even enlarged by the magnifying effect of the sight glass.
Specificaties
Anzeigeposition
FN - straight, top
Gewicht
0.097 kg
Inbouwpositie
FN - recht, top
Kleur
OR - oranje, RAL 2004
Komt overeen met schroefdraadsteek
2.5
Materiaal
KT - Kunststof
Max. speed/min.
1000
Max. toerental/min.
1000
RoHS
Ja
Teller
0002.5
Vorm
R - Numerieke waarde neemt toe bij rotatie met de klok mee
Weergave na 1 spindelomwenteling
0002.5
Zählrichtung
R - Numerical value increasing with clockwise rotation
Zählwerk (mit einer Dezimalstelle)
0002.5
