Beschrijving
Body: Dimensions: H 1045 x W 785 x D 510 mm, Working platform with cover made of ABS plastic with front flattening and anti-roll edge, as well as small additional storage compartments, Manoeuvrable and easy to control thanks to the driving and steering handle, Side walls with Euro perforation 10 x 38 mm to fix hooks and tools, Sides rounded off – a minimum of abutting edges, Body welded, self-supporting and torsionally rigid, Sheet steel, corrosion-resistant and scratch-resistant powder-coated, GEDORE blue, Drawers: Individual drawer stopping stops more than one drawer being opened, one-handed operation, Central locking with cylinder lock, 7 wide drawers (W 640x D 400 mm) fully extending, Ball-bearing guide rails, Load capacity per drawer 20 kg, Sheet steel, corrosion resistant and scratch-proof powder-coated, GEDORE chassis: Total load capacity 400 kg, 4 smooth running wheels on ball bearings (swivel castors Ø 125 mm) with thread guard, one with total brake, Also in case of maximum loads: smooth running, manoeuvrability and track-keeping, Options: Can be equipped with GEDORE tool modules (No. 1500 ES, 1500 CT, 2005 CT, TS-147, TS-190, TS-308), Can be individually equipped with lengthwise and crosswise dividers, Special colors and designs on request, Delivery without tools and accessories






Specificaties
Aantal dwarsverdeler
optioneel beschikbaar
Aantal laden
7
Aantal lengtedeler
optioneel beschikbaar
Aantal wielen
4
Afmeting (L x B x H)
1.045 x 505 x 870 mm
Diameter bokwielen (2x)
125
Draagvermogen per lade
20 kg
Kleur
RAL 5017
Lockable
Ja
Materiaal
Plaatstaal
Nettogewicht
85000 g
Nominale breedte
870 mm
Nominale hoogte
1045 mm
Nominale lengte
505 mm
Oppervlakte
Gepoedercoat
RAL-kleur
blauw
Single pull-out stop
Ja
Statisch draagvermogen
400 kg
Totale breedte
505 mm
Totale hoogte
1045 mm
Totale lengte
870 mm
Werkhoogte
1.045
Zwenkwiel diameter met rem (2x)
125
