Beschrijving
Angle Grinder GWS 12-125, Finding an easy to use and comfortable angle grinder for everyday use can be a challenge. That is why we developed the GWS 12 product family. The GWS 12-125 Professional with anti-vibration side handle is compact, convenient, economical yet powerful. When using this tool, you will appreciate more comfort and less fatigue thanks to the ergonomic design due to the reduced grip size and the anti-vibration side handle. The robust motor has a good overload capability so you will have a fast working progress in your daily metal applications. For easy handling, the tool is equipped with a keyless guard and comes with a lockable switch. It also has Restart protection and we included a plastic clip-on cutting guard for cutting applications in our scope of supply. The GWS 12-125 Professional with anti-vibration side handle is your everyday tool for grinding and cutting metal, tiles, and masonry. It is compatible with the dust extraction guard GDE 125 EA-T Professional and GDE 115/125 FC-T Professional. Cardboard box, Vibration Control auxiliary handle (2 608 900 000), Protective guard (1 605 510 365), Protective clip-on cutting guard plastic (2 608 000 757), Backing flange (1 605 703 099), Locking nut (1 603 340 040), Two-hole spanner (1 607 950 043)
Specificaties
Boring, Ø
22.2 mm
Gewicht
2.2 kg
Hoofdhandgreep
Handgreep
Leerlaufdrehzahl, bis zu
11.000 min-1
Meetonzekerheid k (oppervlakschuren (opruwen)
1.5 m/s²
Meetonzekerheid k (schuren met schuurpapier)
1.5 m/s²
Nominaal ingangsvermogen
1200 W
Nominaal onbelast toerental
11000 min-1
Onbelast toerental
11000 min-1
Potborstel, Ø
75 mm
Schijf Ø
125 mm
Slijpspindel draad
M14
Spanningsbereik
220 - 230 V
Spanningsbereik, tot
230 V
Spanningsbereik, van
220 V
Trillingsemissie ah [schuren met schuurpapier].
4.9 m/s²
Trillingsemissie ah [vlakslijpen (opruwen)]
6.9 m/s²
Uitgangscapaciteit
690 W
