Beschrijving
Angle Grinder GWS 17-125 SB, The GWS 17-125 SB Professional with Speed Selection and Intelligent Brake System that enables fast accessory standstill when the tool is switched off. Improved dust protection by air inlets at the backside of the tool and a significantly small grip size result in high performance and maximum productivity. Drop Control, KickBack Control, Restart Protection, and Vibration Control side handle provide a high level of user protection. The GWS 17-125 SB Professional is perfect for grinding metal or welding seams and cutting metal, concrete, bricks, and tiles. It is compatible with Bosch’s dust extraction systems GDE 125 EA-T Professional and GDE 115 / 125 FC-T Professional. Additional features are Speed Selection, Constant Speed, Soft Start, and Overload Protection. Cardboard box, Vibration Control auxiliary handle (2 608 900 000), Protective guard (1 605 510 365), Protective clip-on cutting guard metal (2 608 000 756), Two-hole spanner (1 607 950 043), Backing flange (1 605 703 099), Locking nut (1 603 340 040), Dust filter (2 607 432 053), SDS quick-locking nut (1 603 340 031)
Specificaties
Boring, Ø
22.2 mm
Gewicht
2.3 kg
Hoofdhandgreep
Handgreep
Idle speed, from
2800 min-1
Idle speed, up to
11500 min-1
Meetonzekerheid k (oppervlakschuren (opruwen)
1.5 m/s²
Meetonzekerheid k (schuren met schuurpapier)
1.5 m/s²
Nominaal ingangsvermogen
1700 W
Onbelast toerental
2800 - 11500 min-1
Packaging dimensions (width x length x height)
130 x 390 x 160 mm
Schijf Ø
125 mm
Slijpspindel draad
M14
Spanning, elektrisch
230 V
Spanningsbereik
220 - 240 V
Spanningsbereik, tot
240 V
Spanningsbereik, van
220 V
Tool dimensions (length)
326 mm
Trillingsemissie ah [schuren met schuurpapier].
3.2 m/s²
Trillingsemissie ah [vlakslijpen (opruwen)]
4.6 m/s²
