Rändelgriff
GN 7336.5-34-M6-15-MS Gewindestift Edelstahl MS-DruckzapfenKU - Plastic
Item-no.: 1212329Supplier number: 7336.5-34-M6-15-MSEAN: 4045525855496
Quantity:
1 PiecePackable
Item available in 36 variants:
Price and stock visible after login
Description
Knurled screws GN 7336.5, type MS/KU with brass or plastic pivots are used when pressure dents or damage must be avoided. Knurled screws GN 7336.5, type ZK feature a spherical pivot whose Ø d6 is smaller than the core Ø of the thread. The version with spherical pivot is suitable for holding GN 631 / GN 631.5 thrust pads, which must be ordered separately. The knurled screws GN 7336.5 distinguish an attractive design in combination with closed shape (no recess on the underside of the handles).
Attributes
Form
MS - Brass plunger
Handle diameter d1
34
L2
1
Material
KU - Plastic
RoHS
Ja
Screw thread d2
M 6
Thread length l1
15
Weight
0.016 kg
d3
16
d4
4
d5
3.5
d6
4.5
h1
21
h2
10.5
l3
1.3
l4
5.1
