Elesa

Position indicator orange

GN 953-000.50-AN-L-OR Elesa CE.82104
KT - Plastic
Item-no.: 1216378Supplier number: 953-000.50-AN-L-OREAN: 4045525522732
Quantity: ​​ 1 PiecePackable​
Item available in 964 variants:
Short-term Sourcing
Description
Position indicators GN 953 have a direct coupled drive with digital indication. The two housing parts are ultra-sonically welded, thus the housing is particularly sturdy and compact. The foam rubber seal prevents the transmission of vibration to the counter and also acts as a seal. The numbers are easily legible and they are even enlarged by the magnifying effect of the sight glass.
Attributes
Anzeigeposition
AN - diagonal, top
Colour
OR - orange, RAL 2004, glossy
Corresponds to thread pitch
5
Counter
000.50
Display after 1 spindle revolution
000.50
Form
L - Numerical value increasing with anti-clockwise rotation
Installation position
AN - diagonal, top
Material
KT - Plastic
Max. speed/min.
500
Max. speed/min.
500
RoHS
Ja
Weight
0.097 kg
Zählrichtung
L - Numerical value increasing with anti-clockwise rotation
Zählwerk (mit zwei Dezimalstellen)
000.50
