Combinatiesleutel, haaks
SW30 mm L340 mm Form A Gedore 7 30Art.-Nr.: 1027795Leveranciersnummer: 7 30EAN: 4010886609125
VPE (Verpakking): 10 stukAantal:
1 stukPakketgeschikt
Artikel in 25 varianten beschikbaar:
Prijs en voorraad zichtbaar na login
Beschrijving
Acc. to DIN 3113, Form A, ISO 3318, ISO 7738, Chrome-vanadium steel 31CrV3, chrome-plated, Carefully forged and professionally machined, Slim jaw and jaw walls make this spanner lighter overall, Jaw: ground precisely to exact nominal size for optimum contact areas, Ring: 15° offset from shaft, with UD profile for gentle transmission of force, Overloading indicated by deformation, Secure grip thanks to hollow shaft - very ergonomic and handy, Glare-free look due to matt chrome, Designed for universal use, Top-grade industrial quality for the hardest of continuous use, Size 3 to 5.5 with hexagonal ring, from 6mm with UD profile, * not standardised
Specificaties
Gesamtbreite
62 mm
Gesamthöhe
27 mm
Gesamtlänge
340 mm
Kopfbreite 1
43 mm
Kopfbreite 2
63 mm
Kopfhöhe 1
17 mm
Kopfhöhe 2
9 mm
Lengte (batterij)
340 mm
Materiaal
CV-staal
Maulstellung 1
15 °
Netto-Gewicht
0,428 kg
Norm
DIN 3113 Vorm A, ISO 3318, ISO 7738
Oberfläche
verchromt
Ring-Profil
UNIT-DRIVE
Ringwinkel
15 °
Schlüsselweite 1
30 mm
Sleutelwijdte
30 mm
