Riegler

Glycerine manometer for vacuum

AG 1/2", D100 mm, -1- 15 bar, max 60°C Metal, bottom connection
Item-no.: 1116666Supplier number: 720/6customs tariff number: 90262040EAN: 4047322114455

Quantity: ​​ 1 PiecePackable
Item available in 47 variants:
Short-term Sourcing

Description
Glycerine pressure gauge with metal housing, Connection radial bottom, G 1/2, Goods class 1.0, Measurement range -1/+15 bar, Ø 100. Glycerine-filled bourdon-tube pressure gauge. For measurements in areas with high, dynamic pressure loads and vibration levels. Suitable for gaseous or liquid media which do not corrode copper alloy, do not have high viscosity and do not crystallise.
Attributes
Ambient temperature max.
60 °C
Ambient temperature min.
-20 °C
Connection
G 1/2
Connection position
Radial bottom
Diameter
100 mm
Flange ring
CrNi steel
Housing
Pressed brass
Lower / upper measuring range limit
Vacuum/overpressure
Material process connection
Copper alloy
Measuring element
Copper alloy
Measuring range max. bar
15
Measuring range min. bar
-1
Medium temperature max.
60 °C
Medium temperature min.
-20 °C
Pointer movement
Copper alloy
Quality class
1,0
Riegler article number
102189
Scale graduation in the bar range
0,5 bar
Screw thread
G 1/2 AG
Type
213.40
Viewing window
Acrylic glass
