1216249 #1
Ganter

Handwheel without handle

DIN 950-GG-250-V17-A Cast iron, square
GG - Cast iron
Item-no.: 1216249Supplier number: DIN 950-GG-250-V17-AEAN: 4045525407886
Quantity: ​​ 1 PiecePackable​
Item available in 31 variants:
Short-term Sourcing
Description
Going beyond the DIN standard, handwheels DIN 950 are also available with Ø d1 = 180 and in types F and D with fixed or revolving handle.
Attributes
Anzahl der Speichen
5
Ballengriff
32
Bore identification
V - with square DIN 79
Bore labelling
V - with square
Form
A - without handle
Form F
96.5
Handwheel diameter d1
250
L1
28
L2
50
Material
GG - Cast iron
R
101
RoHS
Ja
Square s
17
Weight
3.520 kg
b
26
d3
48
d3 ≈
48
d4
M 12
l2 ≈
50
l3 Form D
102
s Square
V 17
