Riegler
Item-no.: 1243420Supplier number: 8306EAN: 4047322120975

Quantity: ​​ 1 PiecePackable
Item available in 53 variants:
Short-term Sourcing

Description
Standard pressure gauge, Single scale bar, Connection radial bottom, G 1/2, Goods class 1.6, Measurement range -1 / +9 bar, Ø 160. Bourdon-tube pressure gauge in standard design. Suitable for gaseous or liquid media which do not corrode copper alloy, do not have high viscosity and do not crystallise.
Attributes
Ambient temperature max.
60 °C
Ambient temperature min.
-20 °C
Connection
G 1/2
Connection position
Radial bottom
Diameter
160 mm
Housing
Sheet steel
Lower / upper measuring range limit
Vacuum/overpressure
Markenzeiger
-
Material process connection
Copper alloy
Measuring element
Copper alloy
Measuring range max. bar
9
Measuring range min. bar
-1
Medium temperature max.
60 °C
Medium temperature min.
-20 °C
Pointer movement
Copper alloy
Quality class
1,6
Riegler article number
101986
Scale graduation in the bar range
0,2 bar
Screw thread
G 1/2 AG
Type
111.10
Viewing window
Instrument glass
